Description
Series advantages
- Variety of pinion shafts are available.
- Bigger bearing and longer distance between two bearings for high side load capability.
- Spline parameters improved from 12/24 to 11/22 in the diameter section.
- Better anti-pollution.
- Patented axial clearance adjustment design to improve the wearing of drive for high reliability .
Technical specifications
| Type | HSP-160 | HSP-200 | HSP-250 |
| Displacement (cm3/rev.) | 160 | 195 | 245 |
| Max.output torque (N·m) | 395 | 425 | 429 |
| Max.differential pressure (bar) | 147 | 137 | 137 |
| Max. speed (rpm) | 80 | 80 | 80 |
| Mechanical brake torque (N·m) | — | — | — |
| Make up pressure (Bar) | 5~10 | 5~10 | 5~10 |
| Valve set pressure(Bar) | 147 | 137 | 137 |
| Mini-Excavator(Ton) | 0.5~1.0 | 1.2~1.5 | 1.5~2.0 |
| Weight(kg) | 16.048 | 16.68 | 17.1 |
