Description
Technical specifications
| Series | HRP04 | ||
| Motor performance | |||
| Displacement | cm3/rev. | 470 | |
| Max.torque | Nm | 2292 | |
| Min.stable speed | rpm | 5 | |
| Max.speed | Displacement | rpm | 420 |
| Variable displacement | rpm | 420 | |
| Pressure | Max.differential pressure | bar | 400 |
| Max.power | kW | 29 | |
| Weight | With brake | kg | 37 |
| Brake | |||
| Minimum static torque | Nm | 2200 | |
| Release pressure | bar | 11 ～ 15 | |
| Maximum pressure at brake port Z | bar | 40 | |
| Oil volume to operate brake | cm3 | 22.9 | |
